A Review of VPN Network Architecture and Internet Safety


Important technical concepts related to a virtual private network (VPN) are covered in this article. A Virtual Private Network (VPN) creates encrypted tunnels over the Internet to connect dispersed workers, company headquarters, and business partners. In addition, VPN access allows off-site workers to access internal networks securely. How do I find the right italy vpn?

The remote desktop or laptop will connect to an ISP through an access circuit like cable, DSL, or wireless. Using IPSec, Layer 2 Tunneling Protocol (L2TP), or Point-to-Point Tunneling Protocol (PPTP), a client-initiated model creates an encrypted tunnel from the laptop to the ISP. The VPN service requires users to verify their identity with the service provider. After that, an encrypted connection is established between the ISP and the VPN router or concentrator at the business.

The remote user will be verified as an authorized staff member via TACACS, RADIUS, or Windows servers. After that, the hidden user must log into their network account via the local Windows domain server, Unix server, or Mainframe host. Since the encrypted tunnel in the ISP-initiated model is only built from the ISP to the company VPN router or VPN concentrator, it is less secure than the client-initiated model. VPN connections are encrypted using either L2TP or L2F.

With an Extranet VPN, an organization’s business partners can securely access internal network resources by connecting their routers to their VPN concentrators. Whether a connection is made through a router or a dial-up modem from a remote location determines which tunneling protocol is used. IPSec and Generic Routing Encapsulation (GRE) are viable options for an Extranet VPN traversing a router. L2TP or L2F will be used for dial-up connections to the extranet. Using the same method with IPSec or GRE as tunneling protocols, the Intranet VPN will securely connect the company’s offices. Using the already-existing Internet to carry business traffic makes VPNs efficient and cost-effective. Many businesses have settled on IPSec as their go-to security protocol for keeping data safe while in transit between a laptop and a router. The components of IPSec that guarantee authentication, authorization, and confidentiality are 3DES encryption, IKE key exchange authentication, and MD5 route authentication.

Security for IP over the Internet

Since IPSec is such a widely used security protocol in modern VPNs, understanding how it functions is essential. IPSec is an open protocol for encrypting IP data transmissions over public networks, as described in RFC 2401. The packet structure comprises the IP header, IPsec header, and Encapsulating Security Payload. IPSec offers authentication via MD5 hashing and encryption via 3DES. Internet Key Exchange (IKE) and Internet Security Association and Key Management Protocol (ISAKMP) automate the exchange of private keys between IPSec peers (concentrators and routers).

The negotiation of one-way or two-way security associations is impossible without these protocols. The encryption algorithm (3DES), hash algorithm (MD5), and authentication method (MD5) make up an IPSec security association. The standard number of security associations (SA) used by Access VPN implementations is three (transmit, receive, and IKE). Instead of using IKE and pre-shared keys for authentication, a Certificate Authority would be used in an extensive enterprise network with many IPSec peer devices.

Personal Computer IPSec VPN Tunnel to a Centralized VPN Server

Agreement on Security Cooperation within the IKE

2 IPSec Tunnel Configuration

Third, RADIUS server authentication via XAUTH requests and responses.

Response/acknowledgment mode for configuration (DHCP, DNS) 4.

Fifthly, the IPSec Security Alliance

Design Access VPN

Using WiFi, DSL, and Cable access circuits from local Internet Service Providers, the Access VPN will facilitate connectivity to the company’s central office at a low cost. The main problem is securing company information as it travels from a telecommuter’s laptop to the primary office over the Internet. Each client laptop will establish an IPSec tunnel to a VPN concentrator, per the client-initiated model.

The Windows-compatible VPN client software will be installed and configured on each laptop. Remote workers must first dial a local access number to connect to their ISP. Next, the RADIUS server verifies the identity of each remote worker before allowing them access. After that, the hidden user will log in to a server running Windows, Solaris, or a Mainframe. Finally, virtual Routing Redundancy Protocol (VRRP) will be set up to fail over two VPN concentrators if one of them goes down.

You’ll find each concentrator between the external router and the firewall. The VPN concentrators have a new security feature that stops malicious denial of service (DOS) attacks from reaching the network. Each telecommuter is given an IP address from a predetermined range, and the firewalls are set up to accept those addresses. In addition, the firewall can be configured to open for any necessary application or protocol.

VPN Layout for an Extranet

Each business partner office can connect safely to the company’s main office through the Extranet VPN. Since all business partners’ data traffic will travel over the Internet, protecting that data is paramount. Each partner will have a dedicated circuit connecting to the VPN router in the company’s main office. In addition, each business partner and its peer VPN router in the central office will use a router with a VPN module.

That component encrypts data packets quickly in hardware using IPSec before sending them over the network. For redundancy in case of link failure, peer VPN routers in the company’s main office are each connected to two separate multilayer switches. As a result, business partner traffic mustn’t flow through the offices of competing partners. The switches connect public servers to an external DNS server and are between the internal and external firewalls. Due to the external firewall’s filtering of public Internet traffic, there is no cause for concern.

In addition, filtering can be set up at every network switch to stop routes from being advertised or security flaws from being exploited through business partner connections made at the company’s core office’s multiple layers of controls. Individual VLANs will be assigned at each network switch for each business partner to secure better and segment subnet traffic. The external firewall at tier 2 checks each packet’s source and destination IP addresses, applications, and protocol ports to see which can safely be opened to business partners. A RADIUS server will be required for all business partner sessions. When that’s done, they’ll log into Windows, Solaris, or Mainframe hosts using their credentials before launching any programs.
